H1208R

Product specifications

Light Sources

650nm Lsaer(Safe visible laser diode)

Scan Tpye

Single Laser

Scan Speed

≥150 times/s

Scan Mode

Manual/Continuous/Automatic Induction Scanning (optional)

Features

Laser

USB

Application Scenarios

Retail

POS

Features

Specifications

PRODUCT FEATURES

• Extended Wireless Range

Boasting a maximum wireless transmission range of 80m, this scanner ensures a stable connection, making it an ideal choice for diverse industries like supermarkets, libraries, hospitals, pharmacies, logistics, retail stores, and warehouses.

• Extended Battery Life

Equipped with a robust 550mAh battery, this scanner can operate for an impressive 15 days on a single charge. This extended battery life enhances productivity and reduces the frequency of recharging, ensuring uninterrupted workflow.

• Versatile Code Interpretation

Featuring a state-of-the-art decoding chip, this scanner can interpret various 1D barcodes not only from paper but also from screens. This versatility makes it suitable for a wide range of applications, adding flexibility to your scanning needs.

• Plug-and-Play Convenience

With a user-friendly design, this scanner is a plug-and-play device, eliminating the need for drivers. Its ease of use simplifies the setup process, allowing users to start scanning immediately without any hassle.

PRODUCT ATTRIBUTES


Light Sources:	650nm Lsaer(Safe visible laser diode)
Supported Symbologies:	UPC-A,UPC-E,EAN-13,EAN-8,Codabar,
	Code 39,Code 39 Full ASCll,China Post,
	Plessey,MSl,Code 93,Code 128,Industrial 2 of 5,Interleave 2 of 5,Matrix 2 of 5,Code 11,
	ISBN,ISSN,Code 32(ltalian pharm code),
	Code 39 extended,ITF-14,RSS14,etc.
Scan Tpye:	Single Laser
Scan Speed:	≥150 times/s
Scan Mode:	Manual/Continuous/Automatic Induction Scanning (optional)
Scan Angle	Yaw 55°,Rotation 30°,Pitch 65°
Precision:	4mil
Depth of scan field:	10-250mm(0.33mm,PCS90%)
Error Rate:	1/5 million
Interface:	USB-HID
Operating Frequency:	2.4G
Transmission distance:	50-80M(Open Yard)
Storage Ability	512000 Bytes
Pairing Mode	One to One
Dimensions	79.7mm69mm187mm
Weight	195.4g
Material	ABS+PC
Cable Length	60cm
Operating Temperature	-20℃~50℃
Storage Temperature	-40℃~70℃
Relative Humidity	5%~95%RH(Non-condensing)
Shock Resistance:	Withstands multiple times 1.5 meters drops to concrete
Voltage	DC5V±10%
Lithium battery	550mA
Current	85mA(Working);150uA(Standy)
