D2505

Product specifications

Illumination

625nm LED

Scan principle

Imaging CMOS

Trigger mode

Manual mode/sensing mode/continuous mode

Scan angle

Roll 360°, Pitch 65°, Skew 75°

System compatibility

Linux, Android, Windows XP, 7, 8, 10,MAC

Features

CMOS

USB

RS232(optional)

Application Scenarios

Supermarket

Retail

Features

Specifications

PRODUCT FEATURES

• Cutting-Edge Decoding Technology

Independently developed core decoding technology ensures outstanding reading performance.

• Soft Illumination Design

LED light distributed lighting offers gentle and non-dazzling illumination, preventing eye fatigue during extended use.

• Enhanced User Interaction

Utilizes multiple prompts with a buzzer and LED indicator feedback method, facilitating intuitive operation.

• Robust Durability

Constructed with sturdy hardware, featuring an IP42 protection level and a 1.5-meter anti-drop height, ensuring durability in various environments.

• Versatile Interface Compatibility

Supports USB/RS232 interface options to accommodate diverse interface requirements, enhancing compatibility for a wide range of customer needs.

PRODUCT ATTRIBUTES


Illumination	625nm LED
Symbologies	1D: EAN13, EAN8, UPC-A, UPC-E, UPC-E, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSIPlessey, RSS-14, limited RSS, extended RSS Standard 2 of 5, Plessey, China Post25, etc.
	2D: QRCode, PDF417, MaxiCode, Aztec, DataMatrix (ECC200),Micro QR, Hanxin Code, Micro PDF417
Scan principle	Imaging CMOS
Trigger mode	Manual mode/sensing mode/continuous mode
Scan angle	Roll 360°, Pitch 65°, Skew 75°
Accuracy*	≥4.5mil
Depth of Field (typ.)*	UPC: 2.0~28cm(13mil)
	Code 39:2.0~13cm( 5mil)
	QR code: 2.0~24.0cm( 20mil)
Interface	USB-HID, RS232 (optional), USB-COM
System compatibility	Linux; Android; Windows XP, 7, 8, 10; MAC
Dimension	85mm(L)85mm(W)150mm(H)
Weight	320g
Voltage	DC 5V ± 5%
Operating current	210mA
Material	ABS+TPU
Cable length	1.8 meter
Operating Temp.	-20 °C to 55°C
Storage Temp.	-20 ℃ to 60 ℃
Humidity	5%-95% (non-condensing)
Anti-seismic capacity	Passed 1.5m rolling drop test
