Home Products Barcode Scanner Barcode Scan Module / Engine for Access Control C4B

C4B

Product specifications

Card reader type

EM card or Mifare card

Communication method

Wiegand 26/34/RS232/RS485/TTL

Reading distance (QR code)

0-20cm

Size

86mm*86mm*18mm

Features

1D Barcode

2D Barcode

NFC

CMOS

USB

Wiegand26/34

RS232

RS485

TTL

Applications

Access Control

Features

Specifications

PRODUCT FEATURES

• Rapid Scanning

The product boasts fast scanning speed, allowing for quick and efficient access control and management.

• High Recognition Rate

It has a high recognition rate, ensuring accuracy in reading QR codes and RFID tags..

• Strong Compatibility

The reader is compatible with any Wiegand input controller, making it adaptable to diverse application scenarios.

• Wide Application

It finds extensive utility in various sectors, including business office buildings, scenic spots, communities, and administrative halls for visitor entry, tourism personnel oversight, and access control.

PRODUCT ATTRIBUTES


Card reader type	EM card or Mifare card
communication method	Wiegand 26/34/RS232/RS485/TTL
Reading direction (bar code)	Angle 45° with the lens as the center point
Operating Voltage	8-12V
Card reading distance (card)	3~6CM
Reading distance (QR code)	0-20cm
Working humidity	10%~90%
operating system	WindowsXP/7/8/10), Linux
Indicator light	Blue work light, green feedback light
Barcode type	QR, one/two-dimensional code
Decoding mode	Image decoding
Scan code characteristics	Automatic induction, buzzer prompt
Working current	800mA
Reading speed	＜200ms
Material quality	Zinc alloy frame + acrylic panel
Operating temperature	-20℃~70℃
Size	86mm×86mm×18mm
